Delivery program sheets - rods - tubes

Material no.:
1.4016, 1.4021, 1.4034, 1.4301, 1.4401/04, 1.4462, 1.4541, 1.4571, 1.4828, 1.4841 and other materials on request

Formats:

• 2000 mm x 1000 mm
• 2500 mm x 1250 mm
• 3000 mm x 1500 mm
• 4000 mm x 2000 mm

Versions:
in accordance with DIN EN 10259 / DIN EN 10029
Materials in accordance with DIN EN 10088-2

• hot rolled
  • e.g. Il A now 1 D
• cold rolled
  • e.g. III C now 2 B
  • e.g. III D now 2 R

Surfaces:
Cold-rolled sheets also available in ground, brushed, “Duplo” ground or polished versions

Special sheets:
textured / patterned rolled sheets, such as: various tear plates, leather grain, ice flower, chessboard, circles, etc.

Formats:

• 2000 mm x 1000 mm
• 2500 mm x 1250 mm
• 3000 mm x 1500 mm

Versions:

• Thin sheets, cold-rolled
  Grades: DC01 (ST 1203), DCO3 (ST 1303), DC04 (ST 1403), S235 (ST 37)
• Thin sheets, also galvanized, in accordance with DIN EN 10142 / 10326 / 10327
  Grades: DX 51 D+Z – 54 D+Z
• Sheet iron S235 (ST 37), hot-rolled from 3 mm
  in accordance with DIN EN 10130/10131
• Sheet steel in grades: C 45, C 60, S355 (ST 52), 16 Mn Cr 5, 42 Cr Mo 4

Versions:

• Welded from sheet metal or strip
• heat-treated and pickled or bright annealed
• unannealed, pickled or bright metal

Dimensional standards according to DIN EN ISO 1127

• Tolerance classes D2/T3 or D3/T3 or D4/T3
• Tolerance annealed tubes D3/13 or D4/13
• Tolerance unannealed tubes standard D3/13

Inspection certificate in accordance with:
DIN EN 10204 / 3.1, test class TC1; AD-W2, test class TC2
3.1 C / A or e.g. LRS – certificates on request

Welded tubes in unannealed or annealed design as:

• Construction and decorative tubes
  e.g. for railing construction
• Line pipes
  • Food pipes DIN EN 11850 / DIN EN 10312
  • Beverage line pipes DIN EN 10312
    e.g. for the food (e.g. DVGW standard) and pharmaceutical industries as well as pipes for domestic installations
• Pipes for pressure loading DIN EN 10217-7
  TC 1, TC 2, welding factor V = 1.0;
  Design type “g” = smoothed inside seam;
  e.g. pipes for pressure vessel, apparatus and pipeline construction
• Precision steel tubes
  • Cold-drawn pipes DIN EN 10305-2
  • Dimensionally rolled pipes DIN EN 10305-3
• Square and rectangular tubes DIN EN 10305-5 in unannealed design

Available surface finishes

• ground according to grain size (240 / 320 / 400 or customer request)
• brushed
• industrial or mirror polished

→ All ground tubes are individually packed in tubular foil

Also available on request:

• Capillary tubes, ring tubes

Versions:

• warm (c2)
• Cold finished: pickled (h) or bright annealed (m); heat-treated

Dimensional standards according to DIN EN ISO 1127 Tolerance classes:

• Cold-finished tubes
  Outer diameter: D2 – D4; wall thickness: 13
• Hot-finished pipes
  Outer diameter: D2; wall thickness: T2

Inspection certificate acc:

• DIN EN 10204 / 3.1, test class TC1; AD-W2, test class TC2
• 3.1 C / A or e.g. LRS – certificates on request

Seamless tubes:

• for general requirements DIN EN 10216
  e.g. for the food and pharmaceutical industries
• for special requirements DIN EN 10216-5
  e.g. pipes for pressure vessel, apparatus and pipeline construction
• for hydraulic and pneumatic pressure lines, cold-drawn DIN EN 10305-4
• as precision tubes, cold-drawn DIN EN 10305-1

If you cannot find your pipe type in this list, please contact us directly.

Stainless steel fittings for:

• the decorative area, partly with polished surfaces
  Pipe caps, plugs, bends, glass clamps, edging profiles, decorative rods and much more.
• the technical area
  T-pieces, bends, nipples, reducers, flanges, dished ends, sockets and much more.

Inspection certificate:
in accordance with DIN EN 10204 / 3.1, partly with AD-W2 /10

DIN EN 10217-7 (previously DIN 17456),
DIN EN 10216-5 (previously DIN 17458)

Forms of delivery:

• Hot rolled / extruded, pickled

Available:

• in HL
• or fixed pieces

Available materials*
and chemical analyses in accordance with DIN EN 10088-2

Materials:
235 (ST 35 / 37-2), 355 (ST 52) etc.

Forms of delivery:

• Seamless precision steel tubes DIN EN 10305-1
• Welded precision steel tubes, cold drawn DIN EN 10305-2
• Welded dimensionally rolled steel pipes DIN EN 10305-3
• Seamless HPL pipes DIN EN 10305-4
• Welded square and rectangular tubes, DIN EN 10305-5
• Welded HPL pipes DIN EN 10305-6
• Railing tubes, seamless boiling tubes, threaded tubes, boiler tubes, hollow steel, hot- and cold-finished hollow steel sections and much more.

Delivery states:

• +N (NBK normalized)
• +С (BK bright / hard)
• +CR1/ BKM / hard)
• +CR2 (BKM / soft) etc.

Surfaces:
phosphated or non-phosphated, galvanized or electrolytically galvanized and/or partially chromated on the outside

Inspection certificate:
in accordance with DIN EN 10204 / 2.2 / 3.1 or on request

Material abbreviations according to DIN EN 10027-1 / DIN 17006-4

• Prefixed letter
  • S – Tubes for steel construction
  • P – Pipes in pressurized application
  • L – Line pipe
  • E – Application in mechanical engineering
• First trailing letter(s)
  • JR – Impact energy 27J at room temperature
  • JO – Notched impact energy 27J at 0° C
  • J2 – Notched impact energy 27J at -20° C
  • G – Filler letter
  • N – normalized / normalizing rolled
  • Q – tempered
  • M – thermomechanically rolled
• Second trailing letter
  • R – Room temperature
  • H – High temperature
  • L – Low temperature
  • A – Requirement class A
  • B – Requirement class B
• Last trailing letter
  • H – Hollow profile

Material no.:
1.4021, 1.4057, 1.4104, 1.4301, 1.4305, 1.4401/04, 1.4462, 1.4541, 1.4571, 1.4841, 1.4828
and other materials on request

Forms of delivery:

• Round steel DIN EN 10060
  • Rolled pickled or peeled
  • in production lengths of approx. 4 m – 6 m
  • alternatively forged and peeled, partially hardened and tempered according to DIN EN 7527
• Flat steel DIN EN 10058
  • Rolled stained; in production lengths of approx. 4 m – 6 m
  • cut from strip / sheet metal; in production lengths of approx. 4 m, similar to DIN 1017
• Square steel DIN EN 10059
  • Rolled pickled
  • in production lengths of approx. 4 m – 6 m
• Angle steel DIN EN 10059-1
  • isosceles, rolled stained
  • unequal-legged rolled or extruded
  • in production lengths of approx. 6 m
• Hexagonal steel DIN EN 10061
  • Rolled pickled
  • in production lengths of approx. 4 m – 6 m

Sanding service for rolled and bright materials:

• Round steels:
  ground to highly polished
• Angle, flat and square steels:
  ground on all sides to a mirror finish

Partly with acceptance test certificate:
in accordance with DIN EN 10204 / 3.1 / AD-W2

Material no.:
S235 (ST 37), S355 (ST 52), C 45, C 60, 16 Mn Cr 5, 34 Cr Al Ni 7, 30 Cr Ni Mo 8, 42 Cr Mo 4, 51 Cr V 4 + various tool steels

Versions:

• Round DIN EN 10060
• Square DIN EN 10059
• Flat DIN EN 10058
• Wide flat DIN 59200
• Angle DIN EN 10056-1
• U- and double T-beams DIN 1025/1026

Material no.:
1.4021, 1.4057, 1.4104, 1.4301, 1.4305, 1.4307, 1.4401/04, 1.4462, 1.4541, 1.4571, some with improved machinability and other materials on request

Forms of delivery:

• Round DIN EN 10278
  • in production lengths of approx. 3 m – 3.2 m
  • Tolerance h 9 and other tolerances on request
    Versions:
  • blank
  • bright drawn, ground
  • bright drawn, polished
  • for decorative purposes grain 240 sanded
  • in production lengths of approx. 6 m
• Flat DIN EN 10278
  in production lengths of approx. 3 m -4 m
  Design:
  bright drawn
• Square DIN EN 10278
  in production lengths of approx. 3 m – 4 m
  Design:
  bright drawn
• Angle DIN EN 10277-2
  in production lengths of approx. 3 m – 6 m
  Design:
  blank, drawn sharp-edged
• Hexagon DIN EN 10278
  in production lengths of approx. 3 m – 3.2 m
  Design:
  bright drawn

Material no.:
S235 (ST 37 K), S355 (ST 52 K), C 45 K, 11 S MN 30 +C, 11 S MN PB 30 +C, 16 MN CR S 5 +C /+SH

Tolerance:
H9 according to DIN EN 10278

Version:
drawn

Various types of manufacture e.g. JR, J2 etc.

• Round DIN EN 10277 – Part 2 – 5
• Square DIN EN 10277 – Part 2-5
• Flat DIN EN 10277 – Part 2- 5
• Hexagon DIN EN 10277 – Part 2 – 5
• Angle DIN EN 10277 – Part 2- 5

Material no.:
1.4016, 1.4301, 1.4541, 1.4571 and many others, bright drawn, annealed, quenched and tempered, also in hardenable grades, in rings or straightened on bars

Material no.:
1.4034 and 1.4116 cold-rolled and also C 75 in rings and bars

Materials:
Al 99.5, Al Mg 1/3/5, Al Mg Si 1, Al Mg 4.5 Mn, Al Mg Si 0.5 etc.

Sheets

Versions:
in various strengths
DIN 1712 / 1725 / 1745 / 1783 / 59600 / 59605

Formats:

• 2000 mm x 1000 mm
• 2500 mm x 1250 mm
• 3000 mm x 1500 mm
  cut to size on guillotine shears

Special sheets:
Duet / quintet sheets, hammer blow

Bar material

in production lengths of approx. 3 – 6 m
DIN 1712 / 1725 / 1747

Versions:

• Round DIN 1798 / 1799
• Flat DIN 1769 / 1770
• Square DIN 1796 / 59700
• Hexagon DIN 1797 / 59701
• Angle / U-profiles DIN 1748 / 1771
• Round and hexagonal material in special

Drilling and turning quality:
Al Zn 4.5 Mg 1, Al Zn Mg Cu, Al Cu Mg Pb

Inspection certificate:
in accordance with DIN EN 10204 / 2.2 / 3.1

Tubes

in production lengths of approx. 3 m – 6 m
DIN 1712 / 1725 / 1746 / 1748 / 9107 / 1795

Versions:

• round
• square
• rectangular

Materials:
CU ZN 37 (Ms 63), CU ZN 39 Pb 2/3 (Ms 58), CU ZN 40 MN, etc.

Sheets

Versions:
soft, semi-hard and hard
DIN 17660 / 1751 / 17670

Formats:

• 2000 mm x 600 mm
• 2000 mm x 1000 mm
• 2500 mm x 1250 mm

cut to size on guillotine shears

Special design:
Tombak sheets

Bar material

in production lengths of approx. 3 m
DIN 17660 / 17672

Versions:

• Round DIN 1756 / 1782
• Flat DIN 1759
• Square DIN 1761
• Hexagon DIN 1763
• Angle DIN 17674

Inspection certificate:
in accordance with DIN EN 10204 / 2.2 / 3.1

Tubes

in production lengths of 3 m – 5 m
DIN 17660 / 17671/ 1755 / 59750 / 59752

Versions:

• round
• square
• rectangular

Special profiles on request

Materials:
SF-Cu, SE-Cu, E-Cu

Sheets

Versions:
soft, semi-hard, hard
DIN 1787 / 17670 / 1751 / 40500

Formats:

• 2000 mm x 1000 mm
• 2500 mm x 1250 mm

Rod material

in production lengths of 3 m – 4 m
DIN 1787 / 40500

Versions:

• Round DIN 1756 / 1782
• Flat DIN 1759
• Square DIN 1761 / 17674
• Hexagon DIN 1763 / 17674
• Angle DIN 17674
  Special profiles on request

Inspection certificate:
in accordance with DIN EN 10204 / 2.2 / 3.1

Tubes

in production lengths of approx. 5 m
DIN 1787 / 17671 / 1754 / 1786 / 8905 / EN 12735

Strength levels:
R220 (soft); R250 (semi-hard); R290 (hard)

Delivery forms:
round, square

• as straightened rods or as ring tubes, installation tubes, refrigerator tubes
• Flat-edged tubes to DIN 1787, EN 13600 for e.g. inductor coils
• Special alloys: CU NI 10 MN 1 FE, (copper-nickel tubes) and many more.

Material:
Cu Sn 6

Sheets

Versions:
soft, spring-hard
DIN 17662 / 17670 / 1751

Formats:

• 2000 mm x 1000 mm
• 2500 mm x 1250 mm

Round bars

in production lengths of approx. 3 m
DIN 17662 / 17672 / 1756

Materials:
RG 5 – 7, GZ-CU Sn 7 Zn Pb

Bar material

in production lengths of approx. 0.5 m – 3 m
DIN 1705

Design:
Round material

Sockets

in production lengths of approx. 0.5 m – 3 m
DIN 1705

Material:
Cu Ni 12 Zn 24

Sheets

DIN 17663 / 17670 / 1751

Versions:
soft, semi-hard, hard, spring-hard

Formats:
2000 mm x 600 mm and much more.
